RP38Si Door Bottom Seal

  • Gap Size: 3mm to 13mm
  • Location: Door Bottom
  • Materials: Anodised aluminium, quality silicon sealing gaskets
$119.43 (inc GST)

NOTE: This is a commercial product, we recommend installation by a second fix carpenter or joiner.

A heavy duty, automatic door bottom seal that is spring loaded to lift clear of the floor when the door is opened. It is self levelling and reversible for left and right handed operation.

IMPORTANT: Seals can be cut back to the previous available size eg. 1067mm cuts back to 920mm. For seal sizes see table below.

Suits Door Types
Double Outward Opening, Single Inward Opening, Single Outward Opening, Door Bottom Seal, Double Inward Opening
Tools Required
Router, circular saw, drill, screwdriver, utility knife & wood chisel
Product Number Barcode Length Colour
A38SIB18 9310459019968 450mm Anodised (Bronze)
A38SIC18 9310459020032 450mm Anodised (Clear)
A38SIB24 9310459019975 610mm Anodised (Bronze)
A38SIC24 9310459020049 610mm Anodised (Clear)
A38SIB36 9310459019982 920mm Anodised (Bronze)
A38SIC36 9310459020056 920mm Anodised (Clear)
A38SIB42 9310459019999 1067mm Anodised (Bronze)
A38SIC42 9310459020063 1067mm Anodised (Clear)
A38SIB60 9310459020018 1500mm Anodised (Bronze)
A38SIC60 9310459020087 1500mm Anodised (Clear)
A38SIB48 9310459020001 1220mm Anodised (Bronze)
A38SIC48 9310459020070 1220mm Anodised (Clear)
